Mower
|
| Cutting Width |
4200 - 42" |
| Cutting Height |
1" - 4" with Deck Height Control System |
| Blades |
4200 - 7/32" x 2 1/2" x 14 1/2", High Lift, Heat Treated |
| Lift and Height Adjustment |
Foot-Assist Lift |
| Blade Belt |
Single V-Belt Spring Tension |
| Anti-Scalp Rollers |
2 Total (2 Front) |
| Deck Flotation |
Floats on 3 Leveling Linkages Along With 2 Anti-Sway Bars |
| Deck Thickness |
1/8" Thick Solid Steel |
Engine
|
| Gross HP/CC |
540cc Air-Cooled Briggs & Stratton |
| Cylinders |
Single Cylinder |
| Displacement |
540 cc |
| Maximum Torque |
28 ft. lbs. at 2,600 RPM |
| Fuel Requirement |
Unleaded Gasoline (87 Octane or Higher) |
| Fuel Capacity |
2.5 Gallons |
| Fuel Filter |
Replaceable Automotive Type |
| Cooling System |
Air-Cooled |
| Ignition |
Electronic |
| Starter |
12 Volt |
| Charging System |
16 Amp |
Drive System
|
| Transmission |
Dual Integrated Hydrostatic Transaxle |
| Pump Drive |
Integrated Axial Piston Pump & Motor w/Gear Reduction |
| Wheel Drive |
Integrated with Gear Reduction |
| Hydrostatic System Oil |
20W50 Motor Oil |
| Hydraulic Filter |
- |
| Pumps (2) |
EZT Integrated Unit |
| Hydraulic Coolers (2) |
7" Cooling Fan Per Unit |
Dimensions
|
| Weight |
4200 - 585 lbs. |
| Overall Height |
42" |
| Overall Width |
42" |
| Overall Length |
67 3/4" |
| Tire to Tire Width |
41" |
| Tires - Front |
11 x 6.0 - 5 Smooth Tread |
| Tires - Rear |
18 x 8.5 - 8 Turf Tread |
| Steering |
Dual Lever Steering, Independent Control |
| Turning Radius |
Zero Turn - Zero Degrees, Turns Within Unit Length |
| Ground Speed (Forward) |
Up To 6 mph |
| Parking Brake |
External Cogg Brake |
