Mower |
|
|---|---|
| Cutting Width | 5400 - 54"; 6100 - 61" |
| Cutting Height | 1" – 5" In 1/3" Increments |
| Blades | 5400 - 1/4" x 2 1/2" x 18 3/4", High Lift, Heat Treated 6100 - 1/4" x 2 1/2" x 21", High Lift, Heat Treated |
| Lift and Height Adjustment | Foot-Assist Manual Lift With Dial-Style Height Adjustment. Optional Electric Lift |
| Blade Belt | Single V-Belt Spring Tension |
| Anti-Scalp Rollers | 6 Total (4 Double-Bracketed Front Wheels, 2 Rear Wheels) |
| Deck Flotation | Floats On Four 1/4" Deck Hangers |
| Deck Thickness | 1/4" Thick Solid Steel With Additional 1/4" Steel Leading Edge And 3/8" Side Trim |
Engine |
|
| Gross Horsepower/CC | 747cc (27hp) Air-Cooled Kohler® Command PRO CV752 |
| Cylinders | V-Twin |
| Displacement | 747 cc |
| Maximum Torque | 41.2 ft. lbs. |
| Fuel Requirement | Unleaded Gasoline (87 Octane or higher) |
| Fuel Capacity | 13 Gallons |
| Fuel Filter | Replaceable Automotive Type |
| Cooling System | Air-Cooled |
| Ignition | Electronic |
| Starter | 12 Volt |
| Charging System | 20 Amp |
Drive System |
|
| Transmission | Hydro-Gear® ZT-4400 Dual Integrated Hydrostatic Transaxle |
| Pump Drive | Integrated Axial Piston Pump & Motor w/ Gear Reduction |
| Wheel Drive | Integrated with Commercial Grade Gear Reduction |
| Hydrostatic System Oil | 20W50 Motor Oil |
| Hydraulic Filter | 25 Micron, Replaceable Spin-On |
| Pumps | - |
| Hydraulic Coolers | 8" 3,600RPM Cooling Fan; One Per Unit |
Dimensions |
|
| Weight | 5400 - 1,270 lbs.; 6100 - 1,325 lbs. |
| Overall Height | 50" |
| Overall Width Chute Up/Chute Down | 5400 - 56 1/2" / 68 1/2"; 6100 - 63 1/2" / 75 1/2" |
| Overall Length | 92" |
| Tire to Tire Width | 5400 - 55 1/2"; 6100 - 55 1/2" |
| Tires - Front | 13 x 6.5 – 6 Smooth Tread |
| Tires - Rear | 24 x 12 - 12 Reaper Tires |
| Steering | Dual Lever Steering, Independent Control |
| Turning Radius | Zero Turn - Zero Degrees, Turns Within Unit Length |
| Ground Speed (forward) | Up To 12 mph |
| Parking Brake | Internal Parking Brake |
